BODY 1 для Yamaha SUN CLASSIC ELECTRIC [G3E] (J46) - 1987 года выпуска
-
№АртикулНазвание
-
1J42-7810A-00-00 FRONT COMPFRONT COMP
-
2J42-7815G-00-00 SEAL, FRONT STORAGESEAL, FRONT STORAGE
-
395811-08030-00 BOLT, FLANGEBOLT, FLANGE
-
490201-084K7-00 WASHER, PLATEWASHER, PLATE
-
590202-09167-00 WASHER, PLATEWASHER, PLATE
-
690202-09169-00 WASHER, PLATEWASHER, PLATE
-
790119-06063-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
890201-06074-00 WASHER, PLATEWASHER, PLATE
-
9J42-77519-00-00 BOLTBOLT
-
1095301-14700-00 NUTNUT
-
11J42-7810E-01-00 FRONT STORAGE LID COMP (J42-7810E-00-00)FRONT STORAGE LID COMP (J42-7810E-00-00)
-
12J42-78153-00-00 HINGE, FRONT LIDHINGE, FRONT LID
-
1398511-04025-00 SCREW, PAN HEADSCREW, PAN HEAD
-
1492990-04200-00 WASHER, PLAINWASHER, PLAIN
-
1595701-04300-00 NUT, FLANGENUT, FLANGE
-
1698701-05016-00 SCREW, FLAT HEADSCREW, FLAT HEAD
-
1792990-05200-00 WASHER, PLAINWASHER, PLAIN
-
1895701-05300-00 NUT, NYLONNUT, NYLON
-
19J42-7810H-01-00 REAR BODY COMP (J42-7810H-00-00)REAR BODY COMP (J42-7810H-00-00)
-
20J42-7814E-00-00 SEAL, BODY SIDE 1SEAL, BODY SIDE 1
-
2195821-08020-00 BOLT, FLANGE (95811-08020-00)BOLT, FLANGE (95811-08020-00)
-
2290201-084K7-00 WASHER, PLATEWASHER, PLATE
-
2390269-06046-00 RIVETRIVET
-
24J42-7717E-00-00 TAPE (NOT AVAILABLE)TAPE (NOT AVAILABLE)
-
25J42-7811J-00-00 BASE, HEADLIGHTBASE, HEADLIGHT
-
26J42-77723-01-00 BRACKET 3BRACKET 3
-
2790480-22084-00 GROMMETGROMMET
-
2890267-40075-00 RIVET, BLINDRIVET, BLIND
-
29J42-78247-01-00 SEAL 3SEAL 3
-
3097706-50125-00 SCREW, TAPPINGSCREW, TAPPING
-
3190201-05033-00 WASHER, PLATEWASHER, PLATE
-
32J42-78122-01-00 REINFORCEMENT 2REINFORCEMENT 2
-
3397313-06016-00 BOLT, HEXAGONBOLT, HEXAGON
-
3492995-06100-00 WASHER, SPRINGWASHER, SPRING
-
3590201-06074-00 WASHER, PLATEWASHER, PLATE
-
36J42-77721-01-00 BRACKET 1BRACKET 1
-
37J42-77722-01-00 BRACKET 2BRACKET 2
-
3897313-08020-00 BOLT, HEXAGONBOLT, HEXAGON
-
3992990-08100-00 WASHER, SPRINGWASHER, SPRING
-
4090480-07241-00 GROMMETGROMMET
-
41J42-7813H-00-00 COVER, VENTILATORCOVER, VENTILATOR
-
42J42-7813M-01-00 HINGE, VENTILATOR 1 (L.H)HINGE, VENTILATOR 1 (L.H)
-
43J42-7813N-01-00 HINGE, VENTILATOR 2 (R.H)HINGE, VENTILATOR 2 (R.H)
-
4497780-50612-00 SCREW, TAPPINGSCREW, TAPPING
-
4592990-05100-00 WASHER, SPRINGWASHER, SPRING
-
46J46-78141-00-00 PANEL, INTERMEDIATE BODYPANEL, INTERMEDIATE BODY
-
47J46-77765-00-00 LABEL, WARNING 5LABEL, WARNING 5
-
48J42-7814A-01-00 SEAL, BODY UPPERSEAL, BODY UPPER
-
4998980-06025-00 SCREW, BINDSCREW, BIND
-
5090201-06697-00 WASHER, PLATEWASHER, PLATE
-
5197780-50612-00 SCREW, TAPPINGSCREW, TAPPING
-
5290201-05556-00 WASHER, PLATEWASHER, PLATE
-
5390338-06184-00 PLUGPLUG
-
5490183-06011-00 NUT, SPRINGNUT, SPRING
-
55J46-78121-00-00 REINFORCEMENT 1REINFORCEMENT 1
-
56J55-K8143-00-00 HINGE, INTERMEDIATE BODY 1HINGE, INTERMEDIATE BODY 1
-
5797013-06012-00 BOLTBOLT
-
5892995-06100-00 WASHER, SPRINGWASHER, SPRING
-
59J55-K8144-00-00 HINGE, INTERMEDIATE BODY 2HINGE, INTERMEDIATE BODY 2
-
6097011-06025-00 BOLT (97001-06025-00)BOLT (97001-06025-00)
-
6192995-06100-00 WASHER, SPRINGWASHER, SPRING
-
6292990-06600-00 WASHER, PLATEWASHER, PLATE
-
6391790-06125-00 PIN, CLEVISPIN, CLEVIS
-
6491490-20015-00 PIN. COTTERPIN. COTTER
-
65J42-7814V-01-00 SEAL, BODY SIDE 6SEAL, BODY SIDE 6
-
66J42-7815A-00-00 PLATE, SEAL SUPPORT 1PLATE, SEAL SUPPORT 1
-
67J42-7815E-00-00 PLATE, SEAL SUPPORT 2PLATE, SEAL SUPPORT 2
-
6890267-32108-00 RIVET, BLINDRIVET, BLIND
-
69J42-7810L-01-00 INSPECTION, LIDINSPECTION, LID
-
70J42-78159-00-00 SEAL, INSPECTION LIDSEAL, INSPECTION LID
-
71J46-78316-00-00 DAMPERDAMPER
-
7298580-06016-00 SCREW, PAN HEADSCREW, PAN HEAD
-
7392995-06100-00 WASHER, SPRINGWASHER, SPRING
-
7490201-06697-00 WASHER, PLATEWASHER, PLATE
-
7590183-06028-00 NUT, SPRINGNUT, SPRING
