BODY 2 для Yamaha SUN CLASSIC ELECTRIC [G3E] (J46) - 1987 года выпуска
-
№АртикулНазвание
-
1J42-7810F-00-00 SIDE PANEL COMP. (L.H)SIDE PANEL COMP. (L.H)
-
2J42-7817A-00-00 COVER, FRONT PILLER (L.H)COVER, FRONT PILLER (L.H)
-
3J42-7717F-00-00 TAPE 2TAPE 2
-
4J42-7817F-00-00 COVER, REAR PILLER (L.H)COVER, REAR PILLER (L.H)
-
5J42-7817H-00-00 TRIM, SIDE PANEL 1TRIM, SIDE PANEL 1
-
6J42-7817J-00-00 TRIM, SIDE PANEL 2TRIM, SIDE PANEL 2
-
7J42-7817K-00-00 TRIM, SIDE PANEL 3TRIM, SIDE PANEL 3
-
8J42-7814F-00-00 SEAL, BODY SIDE 2SEAL, BODY SIDE 2
-
9J42-7814R-00-00 SEAL, BODY SIDE (L.H)SEAL, BODY SIDE (L.H)
-
10J42-7818J-00-00 FLAP, SIDE PANELFLAP, SIDE PANEL
-
1190269-07048-00 RIVETRIVET
-
12J42-7811L-00-00 TRIM, COWL SIDE (L.H)TRIM, COWL SIDE (L.H)
-
1390267-48051-00 RIVET, BLIND (4.8X18.7 BLACK)RIVET, BLIND (4.8X18.7 BLACK)
-
14J42-7814T-01-00 SEAL, BODY SIDE 4SEAL, BODY SIDE 4
-
15J42-78249-01-00 TRIM, FLOORTRIM, FLOOR
-
1690267-48051-00 RIVET, BLIND (4.8X18.7 BLACK)RIVET, BLIND (4.8X18.7 BLACK)
-
1795821-08020-00 BOLT, FLANGE (95811-08020-00)BOLT, FLANGE (95811-08020-00)
-
1897313-08020-00 BOLT, HEXAGONBOLT, HEXAGON
-
1992990-08100-00 WASHER, SPRINGWASHER, SPRING
-
2090201-084K3-00 WASHER, PLATEWASHER, PLATE
-
2190338-24177-00 PLUGPLUG
-
2290338-40178-00 PLUGPLUG
-
23J42-7810G-00-00 SIDE PANEL COMP. (R.H)SIDE PANEL COMP. (R.H)
-
24J42-7817E-00-00 COVER, FRONT PILLER (R.H)COVER, FRONT PILLER (R.H)
-
25J42-7717F-00-00 TAPE 2TAPE 2
-
26J42-7817G-00-00 COVER, REAR PILLER (R.H)COVER, REAR PILLER (R.H)
-
27J42-7817H-00-00 TRIM, SIDE PANEL 1TRIM, SIDE PANEL 1
-
28J42-7817J-00-00 TRIM, SIDE PANEL 2TRIM, SIDE PANEL 2
-
29J42-7817K-00-00 TRIM, SIDE PANEL 3TRIM, SIDE PANEL 3
-
30J42-7814F-00-00 SEAL, BODY SIDE 2SEAL, BODY SIDE 2
-
31J42-7814R-00-00 SEAL, BODY SIDE (L.H)SEAL, BODY SIDE (L.H)
-
32J42-7818J-00-00 FLAP, SIDE PANELFLAP, SIDE PANEL
-
3390269-07048-00 RIVETRIVET
-
34J42-7811M-00-00 TRIM, COWL SIDE (R.H)TRIM, COWL SIDE (R.H)
-
3590267-48051-00 RIVET, BLIND (4.8X18.7 BLACK)RIVET, BLIND (4.8X18.7 BLACK)
-
36J42-7814T-01-00 SEAL, BODY SIDE 4SEAL, BODY SIDE 4
-
37J42-7824A-01-00 TRIM, FLOOR 2TRIM, FLOOR 2
-
3890267-48051-00 RIVET, BLIND (4.8X18.7 BLACK)RIVET, BLIND (4.8X18.7 BLACK)
-
3995821-08020-00 BOLT, FLANGE (95811-08020-00)BOLT, FLANGE (95811-08020-00)
-
4097313-08020-00 BOLT, HEXAGONBOLT, HEXAGON
-
4192990-08100-00 WASHER, SPRINGWASHER, SPRING
-
4290201-084K3-00 WASHER, PLATEWASHER, PLATE
-
4390338-24177-00 PLUGPLUG
-
4490338-40178-00 PLUGPLUG
-
45J42-78314-00-00 COVER, SUN ROOFCOVER, SUN ROOF
-
46J42-78315-00-00 TRIM, ROOFTRIM, ROOF
-
47J42-7831K-00-00 END, ROOF TRIMEND, ROOF TRIM
-
4897780-50320-00 SCREW, TAPPINGSCREW, TAPPING
-
4990209-05275-00 WASHERWASHER
-
50J42-7832A-00-00 REFLECTOR, SUN ROOFREFLECTOR, SUN ROOF
-
51J42-78312-01-00 SUPPORT, SUN ROOF 1SUPPORT, SUN ROOF 1
-
52J42-78349-02-00 CAP, SUPPORT ROOFCAP, SUPPORT ROOF
-
53J42-78381-01-00 BRACKET, MIRRORBRACKET, MIRROR
-
54J42-78382-00-00 JOINT, SCREWJOINT, SCREW
-
5597706-40510-00 SCREW, TAPPINGSCREW, TAPPING
-
5690480-14229-00 GROMMETGROMMET
-
5790209-10229-00 WASHERWASHER
-
58J42-78326-00-00 BRACKET 4BRACKET 4
-
5997026-06012-00 BOLTBOLT
-
6092906-06100-00 WASHER, SPRINGWASHER, SPRING
-
6197312-08025-00 BOLT (97012-08025-00)BOLT (97012-08025-00)
-
6292990-08100-00 WASHER, SPRINGWASHER, SPRING
-
6390201-08730-00 WASHER, PLATEWASHER, PLATE
-
64J42-78313-00-00 SUPPORT, SUN ROOF 2SUPPORT, SUN ROOF 2
-
6590560-10023-00 SPACERSPACER
-
6695303-10600-00 NUT (95301-10600-00)NUT (95301-10600-00)
-
6790170-10186-00 NUTNUT
-
68J42-7832F-01-00 GROMMET, ROOF SUPPORT 1GROMMET, ROOF SUPPORT 1
