ELECTRICAL 2 для Yamaha SUN CLASSIC ELECTRIC [G3E] (J46) - 1987 года выпуска
-
№АртикулНазвание
-
133M-83350-20-00 FLASHER RELAY ASSYFLASHER RELAY ASSY
-
2J42-83350-00-00 FLASHER RELAY ASSYFLASHER RELAY ASSY
-
3J42-85590-01-00 CONTROL UNIT ASSEMBLYCONTROL UNIT ASSEMBLY
-
4J46-82120-00-00 SENDER, BATTERYSENDER, BATTERY
-
538W-85774-00-00 CHECKER, PILOT LAMPCHECKER, PILOT LAMP
-
6J46-83530-00-00 PILOT LIGHT ASSEMBLYPILOT LIGHT ASSEMBLY
-
74G1-84744-00-00 ...BULB (12V-3.4W T-10)...BULB (12V-3.4W T-10)
-
8J50-83514-00-00 PLATE, FITTINGPLATE, FITTING
-
998580-04010-00 SCREW, PAN HEADSCREW, PAN HEAD
-
1092901-04100-00 WASHER, SPRINGWASHER, SPRING
-
1111H-85110-01-00 REFLECTOR ASSYREFLECTOR ASSY
-
1295701-05300-00 NUT, NYLONNUT, NYLON
-
13J42-85140-00-00 REAR REFLECTOR ASSYREAR REFLECTOR ASSY
-
14J42-85115-00-00 BASE, REFLECTORBASE, REFLECTOR
-
1595701-05300-00 NUT, NYLONNUT, NYLON
-
16J42-85130-00-00 REAR REFLECTOR ASSYREAR REFLECTOR ASSY
-
1795701-05300-00 NUT, NYLONNUT, NYLON
-
1892990-05200-00 WASHER, PLAINWASHER, PLAIN
