05- CVT / Transmission для BRP Outlander 400 - 2003
-
№АртикулНазвание
-
1420641268 Flanged torx screw M6 x 30.5Flanged torx screw M6 x 30.5
-
2420610420 CVT coverCVT cover
-
3420630290 CVT cover gasketCVT cover gasket
-
4420641812 Hex screw M12 x 140Hex screw M12 x 140
-
5420627760 Spring washerSpring washer
-
6420684400 CVT drive ass'y. Includes 6 - 22.CVT drive ass'y. Includes 6 - 22.
-
6420280156 Governor cup ass'y. Includes 6 - 9.Governor cup ass'y. Includes 6 - 9.
-
7420281290 Shoe slider setShoe slider set
-
8420233890 Bearing sleeveBearing sleeve
-
9420229585 Roller thrust ass'yRoller thrust ass'y
-
10420280310 Outer half ass'y. Includes 10 - 16.Outer half ass'y. Includes 10 - 16.
-
14420248428 Centrifugal lever set. Includes 14 - 16.Centrifugal lever set. Includes 14 - 16.
-
17420238161 Compression springCompression spring
-
18420627574 Spring seatSpring seat
-
19420257430 ClutchClutch
-
20420632371 Ball bearing 6808Ball bearing 6808
-
21420245950 Retaining ringRetaining ring
-
22420280245 Inner half ass'yInner half ass'y
-
23420229576 Spring sleeveSpring sleeve
-
24420239130 Compression springCompression spring
-
25420941906 Hex screw M10 x 110Hex screw M10 x 110
-
26420627590 Thrust washerThrust washer
-
27420684450 CVT driven pulley ass'Y. Includes 27 - 40.CVT driven pulley ass'Y. Includes 27 - 40.
-
27420280176 Outer half ass'y. Includes 27 - 32.Outer half ass'y. Includes 27 - 32.
-
28420932426 Ball bearing 6205Ball bearing 6205
-
31420660120 Torque gearTorque gear
-
32420245910 Retaining ringRetaining ring
-
33420280235 Inner half ass'y. Includes 33 - 35.Inner half ass'y. Includes 33 - 35.
-
36420238340 Compression springCompression spring
-
37420220911 Driven shaftDriven shaft
-
38420280250 CamCam
-
39420627582 Cam plateCam plate
-
40420280280 V-beltV-belt
-
41420627920 Thrust washerThrust washer
-
42293800070 Loctite 767, antiseize lubricant, 8 ozLoctite 767, antiseize lubricant, 8 oz
