01- Crankshaft, Piston And Cylinder для BRP Rally 175 - 2004
-
№АртикулНазвание
-
1420650165 GasketGasket
-
2420613346 Cylinder Ass'y. Includes 2 - 3.Cylinder Ass'y. Includes 2 - 3.
-
3420929650 Drive PinDrive Pin
-
4420650172 GasketGasket
-
5420613110 Cylinder Head Ass'y. Includes 5 - 7.Cylinder Head Ass'y. Includes 5 - 7.
-
6420253811 Valve GuideValve Guide
-
7420960775 Protection PlugProtection Plug
-
8420240366 StudStud
-
9420842616 Hex. Nut M8Hex. Nut M8
-
10420241481 Socket Screw M6 x 90Socket Screw M6 x 90
-
11205063044 Socket Screw M6 x 30Socket Screw M6 x 30
-
12420222493 Thermostat 65D. Includes 12 - 13.Thermostat 65D. Includes 12 - 13.
-
13420650300 Thermostat GasketThermostat Gasket
-
14420222470 Thermostat CoverThermostat Cover
-
15420941950 ScrewScrew
-
16420650250 Gasket RingGasket Ring
-
17420241841 Socket Screw M5 x 12Socket Screw M5 x 12
-
18420927571 WasherWasher
-
19420251052 Hose ClampHose Clamp
-
20420236490 Chain Tension PistonChain Tension Piston
-
21420238100 Compression SpringCompression Spring
-
22420552276 Hex. Screw M18 x 10Hex. Screw M18 x 10
-
23420552280 O-RingO-Ring
-
24420610440 Valve CoverValve Cover
-
25420650230 Valve Cover GasketValve Cover Gasket
-
26205062044 Socket Screw M6 x 20Socket Screw M6 x 20
-
27420265392 Thermostat Fan SwitchThermostat Fan Switch
-
28420296407 Gasket SetGasket Set
-
29293800060 Loctite 243, 10 mlLoctite 243, 10 ml
-
30293800070 Loctite 767, Antiseize, 8 ozLoctite 767, Antiseize, 8 oz
