FRONT BRAKE для Suzuki VZ1600 K5 - 2005 года выпуска
-
№АртикулНазвание
-
11009K1100-91754 GASKET, DISC PLATEGASKET, DISC PLATE
-
41080K4108-00072-675 DISC, FR, HOUSING GRAY+DISK GRADISC, FR, HOUSING GRAY+DISK GRA
-
43048K4304-80004 PISTON CALIPERPISTON CALIPER
-
43049K4304-90003 PACKING, PISTONPACKING, PISTON
-
43049K4304-91004 PACKING, SEAL, 6.5X11.5X2.2PACKING, SEAL, 6.5X11.5X2.2
-
43049K4304-91107 PACKING, WIPERPACKING, WIPER
-
43057KK430-57003 CAP BREATHERCAP BREATHER
-
43080KK430-80001-7GN CALIPER SUB ASSY (FRONT/LEFT), SILVERCALIPER SUB ASSY (FRONT/LEFT), SILVER
-
43080KK430-80001-8GN CALIPER SUB ASSY (FRONT/RIGHT) SILVERCALIPER SUB ASSY (FRONT/RIGHT) SILVER
-
43082K4308-20031 PAD ASSY BRAKEPAD ASSY BRAKE
-
43085KK430-85001 BREATHER BRAKEBREATHER BRAKE
-
92043K9204-31709 PIN, PADPIN, PAD
-
92145K9214-51568 SPRING, PADSPRING, PAD
-
92150K9215-01771 BOLT, SOCKET, 8X30BOLT, SOCKET, 8X30
-
92153K9215-30360 BOLT, SOCKET, 8X40BOLT, SOCKET, 8X40
-
92153K9215-30577 BOLT, SOCKET, 10X60BOLT, SOCKET, 10X60
