GENERATOR для Suzuki VZ1600 K5 - 2005 года выпуска
-
№АртикулНазвание
-
13078K1307-81056 RATCHETRATCHET
-
13271K1327-11328 PLATEPLATE
-
21003K2100-30008 STATOR (OUTER)STATOR (OUTER)
-
21007K2100-70014 ROTORROTOR
-
21066K2106-61126 REGULATOR VOLTAGEREGULATOR VOLTAGE
-
92001K9200-11947 BOLT, 6X20BOLT, 6X20
-
92009K9200-91768 SCREWSCREW
-
92022K9202-21904 WASHER, 12X40X6WASHER, 12X40X6
-
92150K9215-01484 BOLT, SOCKET, 6X35BOLT, SOCKET, 6X35
-
92153K9215-31105 BOLT, 12X154BOLT, 12X154
